My CBMs

My CBMs: Follow the links for images or more info. The images are between 9 and 60kB in size. (mostly 40kB)

Quick Links:

PET VIC-20 C-64 C-264 C-128 Disk Drives Datassettes Printers Monitors Carts Manuals Other

Guide to the country-codes in the serial#s:

EA is England
UK is the United Kingdom
HB is Hong Kong
WG is West Germany
DA is West Germany

PET:

CBM 220, this specific model is also known as the 8296D. 128kB RAM, internal 8250-drive (1MB per disk). #WG 1729

VIC-20s:

VIC-20, Colour/Brown decals, 5pin video, 2pin power #WG C 21718
VIC-20, Colour/Brown decals, 5pin video, 2pin power, scandinavian keyboard, #WG C 21749
VIC-20, Colour/Brown decals, 5pin video, 2pin power #WG C 29195
VIC-20, #WG C 92111
VIC-20, Square keyboard, #535784
VIC-20, NTSC, #P883438
VIC-20CR, Silver/Black decals, 5pin video, 7pin power, odd keyboard, #WG C 101946
VIC-20CR, NTSC VIC, PAL ROM, #WG C 108219
VIC-20CR, #WG C 326032

C-64s:

C-64, #WG A 38246
C-64, #WG A 137706, square keyboard (pic coming soon)
C-64, #WG A 362377
C-64, #WG C 0848
C-64, scandinavian keyboard, VIC function keys, square psu hole, old(est) motherboard, #WG C 06286
C-64, #WG C 112833
C-64, #UK B 546755
C-64, #UK B 1589185, scandinavian keyboard
C-64, #UK B 1650161
C-64, Jiffydos equipped, reset, drive reset and earphone-plug, in use. #UK B 2039588
C-64, NTSC, #P00217407
C-64, no serial# plate
C-64, Waiting to be fixed, #WG C 226378
C-64, Waiting to be fixed, #UK B 578992
C-64, Waiting to be fixed, #UK B 738971
C-64, Waiting to be fixed, #UK B 1167864
C-64C, brown keyboard, case painted black. #DA4 132611 B1
C-64C, gfx on top of keycaps, #DA4 187436 B1
C-64C, original white keyboard, #DA4 195195 B1
C-64C, original white.., #HB4 36624C
C-64C, original white.., #HB4 118547 B3
C-64C, original white.., #HB4 120001 B3
C-64C, original white.. The "2"-key from a C-64II keyboard. #HB4 150169 B3
C-64C, original white.., #HB4 151253 B3
C-64II, original white keyboard, screwless case holds itself together with clips... Waiting to be fixed, #377949 (W. Germany)
C-64II, gfx on top.., #DA4 259397 B1
C-64II, gfx on top.., #HB4 904405E
C-64II, gfx on top.., #HB4 1128679E
C-64II, gfx on top.., #HB4 1479257E
C-64II, gfx on top.., #HB4 4774747E
C-64II, gfx on top.. Waiting to be fixed, #HB4 043188E
C-64II, gfx on top.. Waiting to be fixed, #HB4 044045E
C-64II, gfx on top.. Waiting to be fixed, #HB4 882759 E
C-64II, gfx on top.. Waiting to be fixed, #HB4 883105 E
C-64II, gfx on top.. strange keyboard, since the look and keycap attachment differs from the usual Mitsumi keyboards. #HB4 1029820 E
C-64II, gfx on top.. Same strange keyboard as the above machine, #HB4 1304992 E
C-64G, gfx on top.. cream breadbox, E-motherboard, as the original had broken down with the previous owner, #DA4 102908
C-64G, Brown keyboard (warranty seal intact), #DA 5191152
SX-64, original condition (used to have scandinavian roms), #GA6 005914 (Japan)
SX-64, good condition, scandinavian roms, #GA6 006080
SX-64, good condition, scandinavian roms, #GA4 000194

C-264s:

C-16, memory expanded to 64kB, has a switch to select 16 or 64kB modes. #EA4 249224
C-16, Mint condition, #EA4 249921
C-16, Mint condition, #EA5 150458
C-16, TED broken, #EA4 249174
C-116, Mint condition, A 5.25" disk is pictured with it so you get an idea how cute and small it is.. #DA4 9522
plus/4, Mint, Boxed with manuals, NTSC, #CA1154917
plus/4, Mint condition (even the warranty seal is still there), #DA4 55131

C-128s:

C-128, NTSC, #CA1467008 (Usa)
C-128, Finnish keyboard, #DA4 187235
C-128, Finnish keyboard, #DA4 296967
C-128, Finnish keyboard, boxed, #DA4 341978
C-128, Finnish keyboard, #DA4 360458
C-128, Finnish keyboard, waiting to be fixed, #DA4 137389
C-128D, Original condition, German/DIN keyboard, #DA4 00603
C-128D, Finnish keyboard, #DA4 51568
C-128D, Jiffydos & Servant, Finnish keyboard, #DA4 91552
C-128D, Mint condition, Finnish keyboard, #DA4 91621
C-128D, Finnish keyboard, #DA4 104565
C-128DCR, Finnish keyboard, #DA4 193518
C-128DCR, Finnish keyboard, #DA4 193553
C-128DCR, Finnish keyboard, drive upper head broken, #DA4 193562

Disk drives:

4040, #504570 (USA)
VIC-1541, long board, #519835 (Japan)
VIC-1541, #1930161, 115V
VIC-1541, long board, #5008400 (Japan)
VIC-1541, cream case, #5803942
1541, long board, #DA4 171467
1541, long board, #DA4 360964
1541, #DA4 361593
1541, long board, #DA4 450245
1541, long board, #DA5 057552
1541, #K 0092579
1541, #K 0095137
1541, awaiting repair, #DA4 179148
1541, awaiting repair, #DA4 325714
1541, awaiting repair, #DA4 362634
1541, awaiting repair, #DA5 062609
1541C, turning door, #DA4 539852
1541C, sliding door, #DA4 571841
1541-II, Newtronics belt-drive mech, #AA3 126174
1541-II, Newtronics belt-drive mech, #AA3 188224
1541-II, Chinon/Sankyo direct drive mech, #BLS 085795 (Hong Kong)
1541-II, Chinon/Sankyo direct drive mech, #BLS 114820
1541-II, Jiffydos equipped, Newtronics belt-drive mech, Green power led, #BLS 918448
1541-II, Digital System Inc. direct-drive mech, Front plate alike Newtronics, no eject spring, Green power-led, #HB5 008767 (China)
1541-II, Chinon/Sankyo direct drive mech, Green power-led, #HB5 073762
1551, Alike 1541, but has a 264-specific parallel interface for fast transfers. #AD4 3288
1570, 1541 mechanism painted white, 1571 motherboard. Single sided burst capable, #DA4 30358
1570, case in bad shape, #DA4 50427
1571, double sided, burst capable, remember always to keep the lever closed when not in use or damage will occur! #DA4 60186
1581, Jiffydos and WD1772 FDC, no serial#-plate.

Datassettes:

C2N, #278656 (Taiwan)
1530, #S 80927279 (Singapore)
1530-4, #1911297 (Taiwan)
1530-4, #2164379 (Taiwan)
1530-4, with box, #3340984 (Taiwan)
1530-4, #JD4 126626 (Taiwan)
1530-4, #JD4 466876 (Taiwan)
1530-5, #JO4 118392 (Taiwan)
1530-6, #XF 936894 (Japan)
1531, black 1530-6, for the 264 series, with box, #XF1 207742
1531, #XF194197 (Japan)
3 fake "Phonemark" Load-IT Datassettes

Printers

MPS801, great condition, #XB4 028131I
MPS1000, Epson Homewriter, European version (switchable charsets)

Monitors:

1701, LCA, CVBS/A
1701, NTSC
1084, Ana+Digi RGB (9-pin D-connector), LCA
1084-P, Ana+Digi RGB (DIN connectors), LCA, made by Philips
1084-P
1084-P
1084S-P, stereo
1084S-P, stereo

Carts:

VIC-1011A, RS-232C Terminal Type, had some rough handling: the bufferchips have been disabled by cutting the pcb, later resoldered.
VIC-1110, 8K Ram Cartridge, aluminium sticker
VIC-1212, Programmer's Aid Cartridge, aluminium sticker
VIC-1902, Star Battle, aluminium sticker
VIC-1907, Jupiter Lander, aluminium sticker
VIC-1907, Jupiter Lander, cream sticker
VIC-1912, Mole Attack, cream sticker
VIC-1913, Raid on Fort Knox, cream sticker
VIC.1915, Pirates Cove, cream sticker
VIC-1922, Cosmic Cruncher, cream sticker
Pirate Adventure for the 264

Manuals:

VIC-20 User Manual, 1981
Commodore 64 MicroComputer User Manual, 1982
Commodore 64 MicroComputer User Manual x4, 1984
Commodore 64 Käyttäjän opas x3, 1986
Commodore 64 Programmer's Reference Guide x2, 1982
Commodore 64 Simons' Basic
Commodore 64 Bedienungshandbuch, 1984
Commodore 16 User Manual, 1984
Commodore 128 System Guide (American)
Commodore 128 System Guide (british) x2, 1985
Commodore 128 & 128D System Guide, 1985
Commodore 128 Johdanto-opas
Commodore 128 Järjestelmäopas x3
Commodore 128D Introductory Guide x2, 1985
Commodore 128 Programmer's Reference Guide, 1986
Commodore Floppy Disk VC1541 User's Guide, 1982
C2N User Manual
1541 Kalvolevyasema Käyttäjän opas x3, 1984
1541-II Levyasema käyttäjän opas x2
Commodore Disk Drive 1570/71 "Users's Guide" x2, 1985
Commodore 1581 Disk Drive user's guide, 1987
Commodore High Resolution Monitor, model 1084 + schematics
Commodore MPS 1000 Dot Matrix Printer User's Manual (photocopied)
VIC-20 RS232-Liitäntä

Other CBM stuff:

C64 powersupplies. Not pictured is the newer brick, which looks like the one on the left, but is white.
1541-II powersupplies. Timo Raita reports to have a larger model of the "brick"-style PSU on the left. Notice how the other one looks like the rightmost C64-supply.
Geomouse(?), joystick emulation only
Handic Software Superbox, cartport multiplier with IEEE488 interface
Oxford Computer Systems Interpod 1, CBM Serial -> IEEE488 + RS232(?)
Action Replay VI
L.A.K.K.N. Eprommer
Scanntronik PageFox, great DTP-utility

Quick Links:

VIC-20 C-64 C-264 C-128 Disk Drives Datassettes Printers Monitors Carts Manuals Other

I'm always looking for new additions, so put me some email if you would like to sell or donate something (no more C-64s :-). They'll get a good home here.
